Cov ntaub ntawv hais txog Rotary Carbide Burrs

Taw qhia:

Carbide teb cov ntaub ntawv tuaj yeem siv los ua cov cam khwb cia hlau, cam khwb cia hlau, carbon steel, hlau alloy, stainless hlau, hardened hlau, tooj liab thiab txhuas carbide teb cov ntaub ntawv, los yog carbide high-speed tov milling cutter, carbide tuag milling cutter, thiab lwm yam. ., feem ntau yog tsav los ntawm cov cuab yeej hluav taws xob lossis cov cuab yeej pneumatic (tseem tuaj yeem ntsia tau rau ntawm cov cuab yeej siv tshuab ceev). Carbide rotary cov ntaub ntawv tuaj yeem txo qis kev ua haujlwm hnyav thiab txo cov nqi tsim khoom.

Cov yam ntxwv tseem ceeb ntawm cov ntaub ntawv teb:

1.Ntau yam hlau (xws li cov hlau tawv tawv) thiab cov khoom siv hlau (xws li marble, jade, pob txha) hauv qab HRC70

tuaj yeem machined ntawm qhov xav tau.

2.Hauv feem ntau ntawm kev ua haujlwm, carbide burrs tuaj yeem hloov lub log me me nrog lub kov, thiab tsis muaj plua plav paug.

3.Nws muaj kev ua tau zoo ntau lawm, kaum tawm lub sij hawm siab tshaj qhov ua tau zoo ntawm cov ntaub ntawv phau ntawv,

ze li kaum npaug siab tshaj qhov ua tau zoo ntawm lub log me me nrog tus kov.

4.Qhov kev ua tau zoo yog qhov zoo, polished heev, thiab pwm kab noj hniav ntawm ntau cov duab tuaj yeem ua tiav nrog

siab precision.

5.Long kev pab cuam lub neej, kaum lub sij hawm siab tshaj lub durability ntawm high-ceev steel, ntau tshaj 200 lub sij hawm siab tshaj

lub durability ntawm alumina sib tsoo log.

6. Yooj yim rau siv, nyab xeeb thiab txhim khu kev qha, tuaj yeem txo kev siv zog, txhim kho qhov chaw ua haujlwm.

7.Cov txiaj ntsig kev lag luam tau txhim kho zoo heev, thiab cov nqi ua tiav tuaj yeem raug txo los ntawm kaum tawm zaus.

Daim ntawv thov ntawm rotary carbide burrs:

1.Nws tuaj yeem ua ntau yam khoom siv hlau, tab sis kuj tuaj yeem ua ≤HRC65 hardened steel.

2.Nws tuaj yeem hloov qhov kov ntawm kev sib tsoo me me, tsis muaj plua plav paug.

3.Qhov kev ua tau zoo ntawm cov khoom tuaj yeem nce los ntawm kaum tawm lub sijhawm piv nrog cov ntaub ntawv kev ua haujlwm dav dav,

thiab qhov ua tau zoo tuaj yeem nce los ntawm 3-5 zaug piv nrog rau kev sib tsoo me me.

4.Cov cuab yeej siv tau ntev dua li cov cuab yeej siv hlau ceev tuaj yeem nce 10 lub sijhawm,

tshaj qhov ua tau zoo ntawm kev sib tsoo me me kuj tuaj yeem nce ntau dua 50 npaug.

5. Nws tuaj yeem ua tiav ntau yam duab ntawm hlau pwm kab noj hniav.

6. Ntxuav lub flash, weld thiab burr ntawm casting, forging thiab vuam.

7. Chamfering thiab grooving ntawm ntau yam khoom siv tshuab.

8. Ntxuav cov kav dej.

9. Kev ua tiav ntawm impeller khiav

10. Cov khoom siv tshuab tiav, zoo li lub rooj sab hauv.

Cov lus ceeb toom thiab ceeb toom ntawm kev siv cov ntaub ntawv teb:

1.Ua ntej ua haujlwm, thov nyeem cov lus siv ntawm kev xaiv qhov nrawm hauv qhov tsim nyog nrawm

(thov xa mus rau cov kev pom zoo pib ceev).

Vim tias qhov ceev ceev yuav cuam tshuam rau cov khoom siv lub neej thiab cov nyhuv machining nto,

thaum qis ceev yuav cuam tshuam rau cov khoom nti tshem tawm, cov neeg kho tshuab chatter thiab hnav ntxov ntxov ntawm cov khoom.

2. Xaiv cov duab zoo, txoj kab uas hla thiab cov hniav zoo rau kev ua haujlwm sib txawv.

3. Xaiv lub tshuab hluav taws xob tsim nyog nrog kev ua haujlwm ruaj khov.

4. Qhov ntev ntawm qhov nthuav tawm ntawm tus kov mounted hauv chuck yog mus txog 10mm.

(Tshwj tsis yog rau qhov txuas ntxiv, qhov nrawm sib txawv)

5. Idling ua ntej siv nws thiaj li yuav xyuas kom meej tias cov concentricity ntawm cov ntaub ntawv teb yog zoo,

eccentricity thiab vibration yuav ua rau hnav ntxov ntxov thiab workpiece puas.

6. Tsis txhob siv nws nrog lub zog ntau dhau, vim nws yuav txo tau lub neej ntawm lub cuab yeej thiab siv kev ua haujlwm zoo.

7. Txheeb xyuas cov khoom ua haujlwm thiab lub tshuab hluav taws xob tuav kom raug thiab nruj ua ntej siv.

8. Hnav cov iav tiv thaiv tsim nyog thaum siv.

Txoj kev ua haujlwm tsis raug:

1.Qhov ceev tshaj qhov siab tshaj plaws ceev ntau yam.

2.Kev siv ceev yog tsawg dhau.

3.Siv cov ntaub ntawv teb daig hauv qhov zawj thiab qhov sib txawv.

4.Siv cov carbide burr nrog lub siab loj heev, kub siab heev, yuav ua rau cov vuam feem poob.

Yog tias koj txaus siab rau cov khoom tungsten carbide thiab xav paub ntau ntxiv thiab cov ntsiab lus,

koj ua tauTiv tauj peblos ntawm xov tooj los yog xa ntawv nyob rau sab laug, lossis xa US MAIL nyob hauv qab ntawm nplooj ntawv no.
