- service: ODM OEM
- Material: tungsten carbide
description
Tungsten carbide strips are also known as rectangular tungsten carbide rods, tungsten carbide flats, and tungsten carbide flat bars,is a sintered metallurgical product of powder form. It is manufactured in vacuum or Hydrogen reduction furnaces with refractory Tungsten material (WC) micron powder as the main ingredient and Cobalt (Co), Nickel (Ni), or Molybdenum (Mo) as the binder.
Grades and Performance of tungsten carbide strip
| ZZBT Grade | ISO Grade | Density (g/cm3) | Hardness (HRA) | T.R.S (MPα) | Grain Size | Performance & Application Recommended |
| UBT910 | K20 | 14.4-14.8 | 90~90.5 | 2200~2400 | Medium | High hardness, suitable for general fiber, aluminum foil, paper making, textile and other mechanical baldes, and can be also used for rough processing of iron, solid wood, dry wood or nonferrous metal, ceramics and other alloys. |
| UBT920 | K30 | 14.2-14.6 | 91~91.5 | 2000~2200 | Fine | High hardness, good toughness and good overall performance. It is suitable for processing all kinds of solid wood, mahogany, medium density board, gray cast iron, non-ferrous metal materials, etc. |
| UBT10T | K10 | 14.6-15.0 | 92.2~92.8 | 1800-2000 | Ultrafine | Untra-fine grain size, high hardness, good wear resistance, suitable for finishing of iron, nonferrous metals, ceramics and other alloys, finishing of hardwood, chipboard, MDF and HDF. Better to use silver soldering. |
| UBT40S | K40 | 13.-13.97 | 90.2~90.8 | 2600~2800 | Fine | On the basis of ensuring high bending strength, the wear resistance of this grade is improved. The cutting edge is dense and sharp, which is conducive to the flatness of processing with good welding performance. It is used for processing food package, printing, aluminum foil, metalized film, gardens, textile, leather, plastic rubber and other mechanical blades. |
| UBT10C | K40 | 13.8-14.2 | 87.5~88 | 2800~3000 | Coarse | High toughness, difficult to break tooth. Special used for finger jointing tool. |
| UBT15N | 13.7-14.0 | 85.0-86.0 | 1700~1900 | Medium | Mainly used for stamping moulds and ceramic die of electronic components, non magnetic. |
Regular sizes of tungsten carbide strip
Tolerance range of tungsten carbide strip:
| Tolerance (mm) | ||
L | >150 | -0~+L*2% |
W | ≤8.0 | -0~+0.35 |
| 8.0~25.0 | -0~+0.50 | |
| 25.0~35.0 | -0~+0.70 | |
| >35.0 | -0~+1.20 | |
| T | ≤15.0 | -0~+0.40 |
* Please contact us for special sizes and minimum order quantity.
What is the value of cemented carbide strip?
Tungsten carbide strip is the preferred material for Woodworking tools manufacturing and Metalworking tools, widely used in the industries which has high requirements for wear-resistance, corrosion-resistance and high-temperature resistance. It has a lot of outstanding performance.
What are the uses of tungsten carbide strip ?
1. Woodworking tools
2. Metalworking tools
3. Molds
4. Textile tools
5. Crushing tools
