Tungsten Carbide Cold Heading Dies For Bolt And Nut
  • Tungsten carbide cold heading die used for punching fasteners. Such as bolts , nuts, nails, studs,ect.

description

undefinedTungsten Carbide Cold Heading Dies For Bolt And Nut

Tungsten carbide heading dies

There are two types of heading dies according to its application environment. If the carbide heading die use in hot environment, we call it hot forging die, or hot forming die. If the tungsten carbide die used in normal temperature condition, we call it tungsten carbide cold heading die, or cold forming die.


Tungsten carbide cold heading dies

Cold forming dies (also called cold heading dies or simply header dies) are used to make steel parts at a high speed and are made of tungsten carbide. The process starts with a cold metal slug being placed into a cold forming die. The slug is then struck by a punch (kind of like a hammer) that forces the slug into the die shaping it into its desired form. The force of the rapid and powerful blow from the punch exceeds the metals yield strength causes the slug to liquefy and form into the cavity of cold forming dies creating a wide variety of parts and products. These include many fasteners such as bolts, nuts, nails and screws. This method, also called heading, can be used to quickly make a wide variety of steel parts. These parts are used in aerospace, automotive and medical to just name a few of the many industries using cold heading machinery. The carbide grades used for cold heading dies usually in YG20, YG20C, YG25 or YG25C, which  consisting of 25% or 20% Co.


Tungsten carbide hot forging dies

According to it’s name we can know that the tungsten carbide dies are used in high temperature condition. One typical factory who use tungsten carbide dies in very high temperature is glassworking wheel manufactures. The tungsten carbide hot forging dies are forging the steel part in a temperature of 700 centigrade. Because of it’s high temperature applying condition, the tungsten carbide grade must keep high hardness even in hot condition. The commonly use carbide grades are with 12%Co, 15%Co, 20%Co.


The advantages of ZZbetter tungsten carbide heading dies

1. Many carbide grades available
2. Numerous sizes available
3. Normal and abnormal shapes available
4. High performance for hot forging and cold heading
5. Maintain good shape in high bending strength
6. Can offer precision grinding service
7. Accept custom design
8. Provide professional suggestions
9. Free sample can be provided
10. Strict quality controlment and short production time


High hardness tungsten carbide cold punching die for cold forging press bolt cold heading die and nut formerHigh hardness tungsten carbide cold punching die for cold forging press bolt cold heading die and nut former

Main grades of tungsten carbide heading dies

undefined

Main shapes and sizes:undefined

Tungsten Carbide Cold Heading Dies For Bolt And NutTungsten Carbide Cold Heading Dies For Bolt And NutTungsten Carbide Cold Heading Dies For Bolt And NutTungsten Carbide Cold Heading Dies For Bolt And NutTungsten Carbide Cold Heading Dies For Bolt And Nutundefined




undefined
